长径比Screw L/D

55:1（加长型Long type）

材料Screw material

38CrMoALA

料筒外径Barrel outside diameter

φ140mm

产量Output

15-40 kg/H.

总装机功率Total power

28KW

螺杆直径Screw diameter

φ75mm

长径比Screw L/D

55:1

发泡倍率Blowing rate

20-40

制品大小Foam net size

10-40mesh

产量Output

15-40kg/H

螺杆螺筒材质Screw and barrel material

38CrMoAlA，表面氮化处理surface nitrided.

驱动形式Drive type

变频电机Frequency converter motor

调速方式Speed regulation

优质变频调速器Transducer of famous brand

驱动功率Drive power

11kw

变速形式Transmission type

硬齿面减速机Hard-surface gear box

冷却方式Cooling type

水冷/风冷By water or by air

加热方式Heating type

铸铝加热器Cast aluminum heater

加热控制方式Heating type

温控表控制Cast aluminum heater(Omron)

加热功率Heating power

20KW

2. 丁烷注入系统Butane pumping system

注入装置Pumping device

柱塞式计量泵（20升）Plunger metering pump (20L)

注入方式Pumping type

高压注入High-pressure pumping

注入压力Pumping pressure

10-30Mpa

驱动功率Driving power

0.75kw

驱动方式Drive type

变频器控制Frequency converter

3. 单甘酯注入系统Monoglyceride pumping system

注入装置Pumping device

柱塞式计量泵Plunger metering pump

注入方式Pumping type

高压注入High-pressure pumping

注入压力Pumping pressure

10-30Mpa

驱动形式Driving type

电机Motor

驱动功率Driving power

0.75kw

4. 机头模具Die

高速机头，动力3kw，变频调速。

High-speed rotating die, power: 3kw, frequency control timing

加热方式Heating type

不锈钢加热圈Stainless steel heating ring

冷却方式Cooling type

风冷Wind cooling

网套型式Net type

可缩口（可编程控制）

Shrinkable(Programmable control)

模具Die

2片, 根据客户要求定做 2pcs, customized.

5. 牵引系统Puller

Power 0.75KW，

变频调速frequency control timing

6. 切断系统Cutter

Power 0.75KW，

变频调速frequency control timing

7.换网系统：net changing device

双工位不停机 two working postion. not stop machine
